Abstract
Yang He1,6,*, Jin-Lu Huang5,*, Kai-Yu Wang1,2, De-Fang Chen2, Yi Geng1, Xiao-Li Huang2, Ping Ou-Yang1, Yi Zhou3, Jun Wang6, Jie Min4 and Wei-Min Lai1
1Department of Basic Veterinary, College of Veterinary Medicine, Key Laboratory of Animal Disease and Human Health of Sichuan Province, Sichuan Agricultural University, Wenjiang, Sichuan, 611130, P. R. China
2Department of Aquaculture, College of Animal Science and Technology, Sichuan Agricultural University, Wenjiang, Sichuan, 611130, P. R. China
3College of Life Science, Sichuan Agricultural University, Ya’an, Sichuan, 625000, P. R. China
4College of Veterinary Medicine, Sichuan Agricultural University, Wenjiang, Sichuan, 611130, P. R. China
5Veterinary Research Institution of Haida, Guangdong, Guangzhou, 511490, P.R. China
6College of Life Science, Neijiang Normal University, Neijiang, Sichuan, 641100, P. R. China
*These authors contributed equally to this work
Correspondence to:
Kai-Yu Wang, email: [email protected]
Keywords: oreochromis niloticus; group B streptococcus; histopathology; ultrapathology; ISH–PCR
Received: April 25, 2017 Accepted: October 28, 2017 Published: January 02, 2018
ABSTRACT
To extend our understanding of the pathogenesis of group B streptococcus (GBS), an infection model was established in the Nile tilapia, and the 50% lethal dose (LD50), the toxicity of the extracellular products, the histopathology, ultrapathology, and dynamic distribution of the bacterium were evaluated. After experimental intraperitoneal (i.p.) infection of the Nile tilapia, the LD50 of GBS resuspended in normal saline was 2.3 × 107 cfu/mL and that of GBS resuspended in bacterial culture medium was 7.7 × 106 cfu/mL. Enzymatic analysis of the extracellular products detected lipase and urease activities. The affected fish showed gross symptoms similar to those of naturally infected fish, including external signs (lethargy, abdominal distension, and abnormal swimming) and internal signs (hemorrhagic liver, enlarged and reddened spleen, hyperemic brain and kidney, empty stomach, and hemorrhagic enteritis). Histologically, hemorrhage, congestion, edema, and necrosis were apparent in the liver, kidney, spleen, heart, and brain. Bacterial colonization was first observed at 2 h postinfection (hpi) in the spleen, 4 hpi in the liver, and 12 hpi in the kidney, brain, and heart. Ultrastructurally, the cells showed nuclear shrinkage, hydropic mitochondrial damage, and increased secondary lysosomes. The bacteria were freely disseminated in the cytoplasm of phagocytes, brain microvascular endothelial cells, neurons, and blood vessels. These results indicate that GBS and their extracellular products are pathogenic to the Nile tilapia, damaging its splenic phagocytes, vascular and renal endothelial cells, liver hepatocytes, and brain neurocytes.
INTRODUCTION
The Nile tilapia (Oreochromis niloticus) is a relatively large cichlid fish, and one of the first fish species cultured worldwide. It is known as the “aquatic chicken” of the human diet, and it is particularly consumed by pregnant women and children [1]. Since the first trial in Kenya in 1920, the tilapia has been cultured in over 100 countries around the world, because its growth rate is high and it is highly tolerant of different culture conditions [2].
Streptococcus agalactiae (group B streptococcus, GBS) is a major Gram-positive coccus-shaped pathogen. Based on the Lancefield classification, it is the only serogroup B streptococcal species [3]. This coccus has become one of the most serious aquatic pathogens, with great ecological and economic impacts. It is a natural pathogen of the tilapia, causing infections around the world, with mortality rates of 30%–100% [4, 5]. The histopathology of GBS-infected tilapia has been described in order to assist its diagnosis [6–8]. Infected fish are characterized by septicemia and meningoencephalitis, with the main clinicopathological signs of lethargy, unilateral or bilateral exophthalmia, corneal opacity, and abdominal distension [9, 10].
Although several studies have documented the virulence factors of GBS, there is still limited information on the interactions between the pathogen and the Nile tilapia. To extend our understanding of the pathogenesis of GBS in the Nile tilapia, an infection model was established, and the median lethal dose (LD50), the toxicity of the extracellular products, the histopathology, ultrapathology, and dynamic distribution of GBS were evaluated in this study.
RESULTS
LD50 values
To determine the pathogenicity of GBS, the LD50 was determined. GBS was isolated from the livers and spleens of all dead fish. The fish injected with GBS or GBS+BC displayed both early- and late-onset disease, and mortality occurred continuously throughout the experiment. After infection, the fish showed 0%–100% mortality in groups A and B, with LD50 values on day 15 of 2.3 × 107 cfu/fish and 7.7 × 106 cfu/fish, respectively (Table 1). The clinical signs induced by GBS and GBS+BC were similar to those in naturally infected fish, including lethargy, opercular hemorrhage, erratic swimming, corneal opacity (Figure 1B), abdominal distension (Figure 1C), and opercular hemorrhage (Figure 1D), except that unilateral or bilateral exophthalmia was not present (Figure 1A). When these fish were dissected, hepatic hemorrhage (Figure 1E), splenomegaly (Figure 1F), thinned intestinal wall (Figure 1G), and meningitis (Figure 1H) were observed. The fish of the control group were active throughout the experiment, and showed neither mortality nor clinical signs.
Table 1: The LD50 of GBS resuspended with 0.85% normal saline or bacterial culture
Group | Bacterial concentration (cfu/mL) | Injection dose (mL) | Number of fish | Number of death | LD50 cfu/mL | |
|---|---|---|---|---|---|---|
Group A | No.1 | 5.8 × 109 | 0.2 | 10 | 10 | 2.3 × 107 |
No.2 | 5.8 × 108 | 0.2 | 10 | 9 | ||
No.3 | 5.8 × 107 | 0.2 | 10 | 7 | ||
No.4 | 5.8 × 106 | 0.2 | 10 | 3 | ||
No.5 | 5.8 × 105 | 0.2 | 10 | 0 | ||
No.6 | NS | 0.2 | 10 | 0 | ||
Group B | No.1 | 6.6 × 109 | 0.2 | 10 | 10 | 7.7 × 106 |
No.2 | 6.6 × 108 | 0.2 | 10 | 9 | ||
No.3 | 6.6 × 107 | 0.2 | 10 | 7 | ||
No.4 | 6.6 × 106 | 0.2 | 10 | 2 | ||
No.5 | 6.6 × 105 | 0.2 | 10 | 1 | ||
No.6 | BC | 0.2 | 10 | 0 | ||
Figure 1: Clinical symptoms of nile tilapia infected by GBS. (A) Healthy tilapia, showing eye (E), opercular (O), liver (L), spleen (S), intestine (I) and brain (a). (B) Unilateral exophthalmia; (C) Corneal opacity; (D) Abdominal distension; (E) Opercular hemorrhage; (F) Hepatic hemorrhage (arrow); (G) Splenomegaly(arrow); (H) Thinned intestinal wall; (I) Meningeal congestion.
Lipase and urease activities in the ECPs
To determine the virulence factors of BC, the ECPs were extracted and the protease, lecithinase, amylase, lipase and urease activities were determined in vitro. The results showed that the ECPs were positive for lipase (Figure 2A) and urease activities (Figure 2B), but negative for all other enzyme activities tested.
Figure 2: Enzymatic activities of ECPs produced by GBS. (A) The lipase activity, white halo around the ECPs; (B) The urease activity, pink halo around the ECPs.
Histopathological changes
To observe the pathological changes induced by GBS, spleen, liver, kidney, stomach, intestine, and brain tissues were sampled and embedded for analysis. The histopathological changes in these tissues were as follows.
Liver
The histopathological changes in the liver mainly presented as structural disorder, congestion, and atrophy. Hepatocytes displayed swelling, vacuolar degeneration, and necrosis. In some infected fish, hepatocytes showed reduced numbers of cytoplasmic vacuoles, which were replaced by increased eosinophilic ovoid hyaline bodies (Figure 3B). Throughout infection, GBS was commonly observed in the central veins (Figure 3Cc), along the hepatic sinusoids, and in the hepatic cytoplasm of the artificially infected fish (Figure 3D).
Figure 3: The histopathology of liver. Control (A) and GBS infected (B, Cc, Dd) H&E. Solid line = 50 μm, dashed line = 25 μm. (A) Normal liver, * showing central vein; (B) Affected liver presented atrophic acinar cells (arrow) and degenerated hepatocytes with less vacuolar and more eosinophilic ovoid hyaline bodies (head arrow); (C) Congested central vein with bacteria attached by wall (head arrow), c. GBS attached to erythrocytes and engulfed by the monocytes (arrow); (D) Affected hepatocytes presented swelling and loss of lipid, d. GBS within hepatic cytoplasm (arrow).
Spleen
Compared with the structure of the normal spleen (Figure 4Aa), the infected samples showed acute hemorrhagic splenitis; the splenic sinus displayed hyperemia and hemorrhage, lymphocytes were reduced, the normal structure of the ellipsoids was disrupted, the reticulate endothelial cells were denatured and damaged, and the number of melanomacrophage centers (MMCs) was increased, with high contents of hemosiderin. GBS was trapped within the walls of the ellipsoids, leading to the focal necrosis of the ellipsoids (Figure 4B), and were engulfed by the reticulate endothelial cells of the red pulp (Figure 4Cc). In some infected fish, the red blood cells of the red pulp disappeared, and GBS aggregated throughout the tissues (Figure 4Dd).
Figure 4: The histopathology of spleen in control (Aa) and GBS infected (B, Cc, Dd) nile tilapia. H&E. Solid line = 50 μm, dashed line = 25 μm. (A) Normal spleen, showing red (R) and white (W) pulps, a. an ellipsoid; (B) Affected spleen presented severe congestion with focal necrosis (arrow); (C) Severe congested red pulps with focal bacterial aggregates, c. bacterial aggregates (arrow); (D) Affected spleen loaded with numerous bacteria, d. Ovoid bacteria-laden phagocytes (arrow), and disrupted phagocytes (head arrow).
Kidney
The most obvious changes were the degeneration and necrosis of the renal cells. The renal hemopoietic tissue was considerably reduced. The glomerulus was enlarged, the capillary network displayed congestion, and Bowman’s capsule became narrow, with caduceus necrotic debris. The epithelia of the renal tubules showed swelling, separated from the basement membrane, and fell off into the lumen (Figure 5Bb).
Figure 5: The histopathology of kidney and brain in control (Aa, Cc) and GBS infected (Bb, Dd) nile tilapia. H&E. Solid line = 50 μm. (A) Normal renal corpuscles, showing glomerulus (G), renal tubules (T), and hemopoietic tissue (*), a. A glomerulus; (B) Affected kidney showed severe tubulonephrosis and sharply decrease of hemopoietic tissue (*), b. Glomerulus congested and necrotic debris fell in the Bowman’s capsule (head arrow); (C) Normal brain, showing thin meninges, c. brain microvessels(arrow); (D) Affected brain showed meningeal congestion (arrow), d. neuron exhibited vacuolar degeneration (head arrow).
Brain
The meninges of the infected fish showed marked thickening, and the parenchyma was loose, with a spongy appearance. The brain microvessels were congested and the vascular spaces widened. The neuronal cells showed swelling and vacuolar degeneration, with small vacuoles in the cytoplasm (Figure 5Dd).
Stomach
The gastric mucosa of the infected fish was degenerated, damaged, and had fallen into the gastric cavity. The gastric gland of the submucosa was distinctly edematous, and the gastric gland cells were swollen and separated from the basement membrane (Figure 6B). The muscular layer showed necrosis, and the muscle fibers were ruptured, with vacuolar degeneration.
Figure 6: The histopathology of stomach and intestine in control (A, C) and GBS infected (B, D) nile tilapia. H&E. Solid line = 50 μm, dashed line = 25 μm. (A) Normal stomach mucosa and gastric glands; (B) Affected gastric gland showed severe edema; (C) Normal intestine mucosa; (D) Affected intestine mucosa showed epithelia necrosis, and inflammatory cell aggregation.
Intestine
The intestinal epithelial cells displayed necrosis and had fallen into the intestinal lumen. The goblet cells were disrupted and reduced in number. The major pathological change in the submucosa was edema (Figure 6D). The muscular layer showed the same changes as the stomach, including vacuolar degeneration and necrosis.
Heart
The normal heart is surrounded by a single layer of cells, with a distinct compact outer layer of muscle and an inner spongy layer, with numerous trabeculae (Figure 7Aa). In contrast, after infection, most of the fish had various degrees of pericarditis and myocarditis. The epicardium was thickened with edema and inflammatory cell infiltration. The myocardial cells showed eosinophilic staining, necrosis, and lysis, and the intercellular spaces had widened. Numerous blue-colored bacteria appeared in the pericardium or attached to myocardial cells (Figure 7Bb).
Figure 7: The histopathology of heart and gill in control (Aa, C) and GBS infected (Bb, Dd) nile tilapia. H&E. Solid line = 50 μm, dashed line = 25 μm. (A) Normal heart structures, showing pericardium (arrow), compact layer (C) and spongy layer (S), a. Normal myocardium; (B) Affected heart presented severe pericarditis (arrow) and myocarditis (*), b. GBS attached to the myocardial cells (head arrow); (C) Normal gill, showing gill filament (F) and lamellae (arrow); (D) Affected gill presented lamellae necrosis (*) and covering respiratory epithelium slough off, d. Bacteria appeared in the pillar cells (head arrow).
Gill
The gill lamellae of a healthy tilapia show the primary lamella (P) with arrays of delicate secondary lamellae (Figure 7C), which are surrounded by a single layer of respiratory epithelial cells. After infection, cell necrosis and shedding were the main symptoms of the secondary epithelium. Numbers of necrotic cells and inflammatory cells were observed between the gill lamellae. The capillaries of the gill lamellae displayed hyperemia, and some GBS were apparent in the pillar cells (Figure 7Dd).
In situ hybridization (ISH)–PCR
The main GBS-containing tissues (spleen, liver, kidney, heart, and brain) were sampled to investigate the dynamic distribution of GBS in the 36 h after infection (Table 2). ISH–PCR revealed GBS within the reticuloendothelial cells of the spleen at 2 hpi (Figure 8A), and in increased numbers at 36 hpi. GBS was first detected in the hepatic sinusoids at 4 hpi (Figure 8B), and strong positive signals were observed in the hepatocytes and hepatic sinusoids at 36 hpi. The numbers of GBS detected in the kidney, heart, and brain were much lower than in the spleen and liver throughout the experimental period. The kidney and heart showed GBS at 12 hpi, mainly in the vessels of the glomerulus (Figure 8C), the renal interstitium (Figure 8D), and the myocardial cells (Figure 8E). The brain was positive for GBS at 24 hpi, which were concentrated in the meninges (Figure 8F).
Table 2: Dynamic distribution of GBS detected using ISH-PCR
Organ | Detection time (h) | |||||
|---|---|---|---|---|---|---|
2 | 4 | 6 | 12 | 24 | 36 | |
Spleen | + | + | ++ | +++ | +++ | +++ |
Liver | - | + | ++ | +++ | +++ | +++ |
Kidney | - | - | - | + | + | + |
Heart | - | - | - | + | + | + |
Brain | - | - | - | - | + | + |
Figure 8: The detection of GBS by ISH-PCR. Solid line = 50 μm. (A) 2 hpi, GBS presented in the splenic reticuloendothelial cells (arrow); (B) 4 hpi, GBS presented in the hepatic sinusoids (arrow); (C) 12 hpi, GBS presented in the glomerulus (arrow); (D) 36 hpi, GBS presented in the phagocytes of renal interstitium (arrow); (E) 12 hpi, GBS presented in the myocardial cell (arrow); (F) 36 hpi, GBS presented in the capillary and phagocytes of meninges (arrow).
Ultrapathology
To observe GBS in the cells of tissues, the ultrapathological changes in the main GBS-containing organs (liver, spleen, kidney, and brain) were observed. The ultrapathological changes in the infected tissues were as follows.
Liver
Increased secondary lysosomes were commonly observed in hepatocytes (Figure 9A). GBS were engulfed and digested by the lysosomes. The hepatocyte mitochondria became swollen and expanded into vacuoles (Figure 9B). The glycogen stores were depleted in most hepatocytes.
Figure 9: The ultrapathology of nile tilapia infected by GBS. (A) GBS dissected within the lysosome of hepatocytes (head arrow), TEM×12000; (B) Swollen hepatocytes with edged nucleus and vacuoles (head arrow), TEM×10000; (C) splenic lymphocytes showed nuclear pyknosis and surrounded by GBS (head arrow), TEM×10000; (D) Bacteria engulfed by splenic neutrophil, TEM×10000; (E) Splenic macrophage showed disrupted membrane (head arrow), enlarged nuclear membrane (arrow) and bacteria in the cytoplasm, TEM×8000; (F) Disseminated bacteria from the ruptured splenic macrophages, TEM×7000; (G) Vacuoles apperared in the renal tubule epithelia (*), TEM×8000; (H) brain microvessel exhibited incomplete (head arrow), and bacteria freed in the lumen, TEM×7000; (I) GBS appeared in the brain microvessel epithelia cell, TEM×12000.
Spleen
Splenic lymphocytes were markedly decreased (Figure 9C). Free bacteria were observed within the cytoplasm of the splenic macrophages and neutrophils (Figure 9D–9F). As the infection progressed, phagocytes showed necrosis and free bacteria were widely distributed.
Kidney
Epithelial cells in the renal tubules showed necrosis. The electron density of the nuclear chromatin decreased, and the mitochondria became swollen and vacuolated (Figure 9G).
Brain
The brain microvessels were broken. GBS were observed in the endothelial cells and microvessels, and the number of neurons clearly decreased (Figure 9H–9I). In their place, the numbers of microglia and inflammatory cells increased.
DISCUSSION
Group B streptococcus is a common fish pathogen, causing significant morbidity and mortality in at least 18 fish species, including tilapia, rainbow trout (Oncorhynchus mykiss) [11], silvery pomfret (Pampus argenteus) [12], and ya-fish (Schizothorax prenanti) [13]. In the present study, the infected fish showed the same external signs as reported in previous studies, including lethargy, unilateral or bilateral exophthalmia, corneal opacity, and abdominal distension due to the extensive accumulation of ascites [4, 14]. Among these symptoms, exophthalmia is a typical clinical sign, displayed by almost all affected species. However, exophthalmia does not occur in all infected fish. A review of the reports of GBS infections suggested that the aquatic species, the bacterial serotype, and the infected environment are associated to some degree with exophthalmia. In Queensland, Australia, spontaneous infections in grouper caused unilateral or bilateral exophthalmia, and in another study, 71.8% of 300 red tilapia displayed exophthalmia [7]. However, in experimental infections, only 18% and 10% of Nile tilapia presented with exophthalmia [10]. This is consistent with the present study, insofar as most naturally infected fish had “pop-eye”, whereas no fish with an experimental infection displayed exophthalmia.
LD50 is frequently used as a general indicator of the acute toxicity of a pathogen [15]. A previous study showed that the 7 day LD50 of S. agalactiae strain HN0101 resuspended in NS was 3.4 × 107 cfu/mL [16]. This is similar to the 15 day LD50 reported here (2.3 × 107 cfu/mL). Extracellular products are important virulence factors of fish pathogens. The LD50 of GBS+BC (7.7 × 106 cfu/mL) was lower than that of GBS+NS. Further analysis of the ECPs showed that they included lipase and urease activities. Lipase hydrolyzes lipid substrates and fulfills diverse functions in bacterial pathogenesis through host cell damage or modulation, inflammation, and cell signaling [17]. Straus [18] showed that the lipases of Pseudomonas cepacia inhibit bacterial phagocytosis by alveolar macrophages. Urease is known to enhance the survival of pathogens by hydrolyzing urea to supply them with nitrogen sources, increase the pH to favor their growth, and damage the surrounding epithelial cells [19]. Therefore, our results imply that the lipase and urease activities in BC contribute to the pathogenicity of GBS.
The spleen plays an important role in the destruction of aged red cells and captures hematogenous pathogens [20]. The high content of hemosiderin within melanomacrophages is a consequence of red cell destruction [21]. This is consistent with our observation that the spleens of infected fish showed fewer erythrocytes and more MMCs than the control spleens. The numbers of ellipsoids and macrophages were also reduced by the deficiency of oxygen and their destruction by virulence factors, and the blood–spleen barrier was impaired, leading to the spread of GBS to other organs (liver, heart, kidney, and brain). This is similar to the results of our previous study [22]. The liver breaks down lipids to meet the body’s metabolic requirements, and the histology of hepatocytes showed the accumulation of large amounts of lipids in the cytoplasm [23]. A previous study showed that the liver becomes congested and edematous after infection [7]. In the present study, we also found lower fat vacuolation in the cytoplasm of hepatocytes, as observed in the liver after short-term mercury challenge [24]. After GBS infection, the Nile tilapia showed a loss of appetite, gastritis, and enteritis, leading to protein and energy break off. Therefore, the lipids in the hepatocytes might have been largely digested, after which the low-fat vacuolation of the hepatic cytoplasm became apparent. The histopathological changes in the brain and kidney were similar to those in previous reports, and indicated severe meningitis and renal tubule degeneration and necrosis [3, 25]. We have reported the histopathology of the fish heart after GBS infection for the first time, which showed serious pericarditis and myocarditis.
GBS can be localized with bacterial culture, PCR, quantitative PCR, ISH, IHC, and transmission electron microscopy (TEM). Among these, only ISH, IHC, and TEM can localize GBS in individual cells. The sensitivity of IHC varies with the type of antibody used [26]. ISH–PCR allows the amplification of target sequences within intact cells and combines high sensitivity with the ability to localize specific DNA in tissues. It is more sensitive than ISH and produces less false positive results than PCR. cpsE encodes a well-conserved polysaccharide-producing protein present in the serotype-determining capsule of GBS [27]. Therefore, it was used as the target for GBS ISH–PCR. The immunohistochemical detection of GBS in red tilapia infected by the immersion route showed that the bacteria were present in the intestine and liver at 30 min post infection, then colonized the spleen and heart at 2 hpi, and appeared in the kidney and brain at 4 hpi [28]. Our ISH-PCR results showed that after i.p. challenge, GBS were first detected in the spleen (2 hpi), followed by the liver (4 hpi), and then the kidney and brain (12 hpi). This discrepancy in the dynamic distribution of GBS might be attributable to the different infection routes used and the different virulence of the GBS. Notably, the spleen contained the largest number of GBS in both studies [28].
As an intracellular bacterium, GBS should be eliminated by a specific type of autophagy, known as “xenophagy” [29]. However, GBS can thwart the xenophagic pathway to invade endothelial cells and survive [30]. In the present study, free GBS was observed in macrophages, lymphocytes, hepatocytes, brain microvascular endothelial cells, and neurons, and induced the necrosis of macrophages and lymphocytes. These results suggest that GBS has evolved strategies to evade phagocytosis, and uses transcytosis to move to a suitable niche to avoid phagocytes. Bacterial debris was commonly observed in phagocytes and hepatocytes, indicating that phagocytosis by phagocytes and hepatocytes is involved in the immune clearance of GBS.
MATERIALS AND METHODS
Bacteria
Streptococcus agalactiae (HN0101) was obtained from diseased Nile tilapia [16] and stored at −80°C until analysis. The bacterium was incubated in brain–heart infusion (BHI) broth (BD, USA) at 30°C for 24 h with shaking. The total bacterial DNA was prepared with the Genome DNA Extraction Kit (TianGen, China, approval no. 2011–028).
Nile tilapia
Healthy Nile tilapia (mean weight 100 ± 5 g) with no history of GBS infection were purchased from a commercial tilapia farm and kept in 120 L aquaria at 30 ± 1.0°C under a 12-h light/dark cycle. The fish were fed a commercial diet at a feeding rate of 3%–5% body weight/day. The animal studies presented in this manuscript were approved by the Animal Care Committee of Sichuan Agricultural University (Wenjiang, China, approval no. 2011–028).
Determination of LD50
The tilapia (120 fish) were divided equally into two challenges: group A was challenged with GBS + 0.85% normal saline (NS), and group B was injected with GBS resuspended in the BHI broth (BC) in which it was cultured for 24 h at 30°C. The fish in each infection group were randomized into six groups (10 fish/group), five for GBS infection (nos. 1–5) and one as the negative control (no. 6). For GBS+NS infection, the bacteria were washed and suspended in NS to a concentration of 5.8 × 109 cfu/mL, and were serially diluted 10-fold to concentrations of 5.8 × 108–5.8 × 105 cfu/mL. The fish in group A (nos. 1–5) were injected intraperitoneally with 5.8 × 109, 5.8 × 108, 5.8 × 107, 5.8 × 106, or 5.8 × 105 cfu/mL bacterial suspension, respectively, at 0.2 mL/fish. Group A no. 6 was injected with NS as the negative control. For GBS+BC infection, the bacteria were directly suspended in BC to a concentration of 6.6 × 109 cfu/mL, and serially diluted 10-fold with bacterial culture medium to concentrations of 6.6 × 108–6.6 × 105 cfu/mL. The fish of group B nos 1–5 were injected intraperitoneally with 6.6 × 109, 6.6 × 108, 6.6 × 107, 6.6 × 106, or 6.6 × 105 cfu/mL bacterial suspension, respectively, at 0.2 mL/fish. Group B no. 6 was injected with BC as the negative control.
Fish mortality was recorded for 15 days, and the LD50 values were calculated according to Koch’s method [31]. The livers and spleens of all the dead fish were sampled for bacterial isolation and identification.
Enzymatic activity of the extracellular products (ECPs)
GBS was incubated in BHI broth at 30°C for 36 h with shaking. The bacterial cultures were then centrifuged at 12,000 × g for 30 min at 4°C. The cell-free supernatants were sterilized with a 0.22 μm microbiological filter and precipitated in 75% saturated ammonium sulfate for 24 h at 4°C. The ECPs were collected by centrifugation at 12,000 × g for 30 min, resuspended, and renatured by dialysis against 0.02 mol/L Tris-HCl (pH 7.5). The protein concentration in the crude ECPs was determined with the Bradford Protein Assay Kit (Takara, code no. T9310A) and standardized to 160 mg/mL. The protease, lecithinase, amylase, lipase and urease activities were determined with the methods described by Yang [32].
Histopathological analysis
Samples of the liver, spleen, kidney, brain, stomach, intestine, heart, and gill of each moribund fish in group A were collected for pathological analysis. The tissues were fixed in 4% paraformaldehyde, processed routinely into paraffin wax sections, and stained with hematoxylin and eosin (HE).
In situ PCR
In situ PCR was performed with the method of Saltz [33], with minor modifications. Tilapia were infected i.p. with GBS (2LD50), and their spleen, liver, heart and brain tissues were sampled, fixed in 4% paraformaldehyde, and processed routinely into paraffin wax sections. The sections were cut to 3–5 μm and rehydrated in an ethanol series and phosphate-buffered saline (PBS). The slides were incubated with 20% acetic acid for 15 s to inactivate any endogenous alkaline phosphatase. The sections were permeabilized by treatment with proteinase K at a final concentration of 0.1 μg/mL for 20 min at 37°C. RNA was removed with DNase-free RNase (10 μg/mL) for 2 h. Finally, the slides were rinsed with distilled deionized H2O (ddH2O) and dehydrated in an ethanol series. The tissues were sealed with 25 μL of PCR buffer: 2.5 μL of 10 × buffer, 4 μL of 25 mM MgCl2, 1 μL of 10 mM dNTP, 1 μL of 5 U/μL Taq DNA polymerase, 13.5 μL of ddH2O, and 1.5 μL of each 10 mM cpsE primer, which are specific for GBS. The primer sequences were 5¢-ATGAAAATTTGTCTGGTTGG-3¢ and 5¢-TTAAAAAATTCCTCCTAAATT-3¢. The PCR thermal program consisted of denaturation at 94°C for 10 min, followed by 30 cycles of 95°C for 1 min, 55°C for 1 min, and 72°C for 1 min, and concluded with 72°C for 10 min. Finally, the samples were fixed with 4% paraformaldehyde for 10 min.
In situ hybridization
Hybridization was performed according to the instructions of the assay kit purchased from Boster of China (cat. no. Mk1032). The samples were prehybridized with prehybridization solution at 42°C for 3–4 h. The GBS-specific probe, cpse (5¢-GAATGGTACTGCTACAGCGGC-3¢) labeled with digoxigenin (DIG; 500 ng/mL in hybridization solution) was spotted onto the samples and denatured at 95°C for 10 min. After incubation at 42°C for 12 h, the unreacted probe was removed from the slides by washing. Blocking buffer was incubated with the samples at 37°C for 30 min, and then replaced by alkaline-phosphatase-conjugated anti-DIG antibody and incubated at 37°C for 120 min. After the samples were washed three times, they were incubated in BCIP/NBT at 37°C for 20–30 min and restained with Nuclear Fast Red. Finally, the stained sections were dehydrated in ethanol, cleared in xylene, covered with cover glasses, and examined with a light microscope (Nikon, Tokyo, Japan). GBS was scored with the following criteria: (−), no GBS, (+) a few scattered GBS; (++), medium amount of aggregated GBS; (+++), massive levels of GBS, with > 80% of the tissue area positively labeled.
Transmission electronic microscope examination
The spleens, livers, kidneys, and brains from the moribund fish of group A were fixed in 2.5% cold glutaraldehyde in 0.1 M PBS (pH 7.2) for 24 h. After The samples were washed twice and post fixed in 1% osmium tetraoxide in 0.1 M PBS (pH 7.2). The postfixed samples were dehydrated in a graded series of acetone (30%, 50%, 70%, 80%, 90%, and 100%), then infiltrated with 1:4 acetone:epon resin for 8 h. After infiltration in pure epon resin for a further 2 h, the samples were embedded in resin. Ultrathin sections were double-stained with uranium acetate and lead citrate, and examined with a transmission electron microscope [34].
ACKNOWLEDGMENTS AND FUNDING
We thank Mrs. Xiao-jiao Li for her assistance in the preparation of the all the materials. The authors declared no potential conflicts of interest with respect to the research, authorship, and publication of this article. This work was supported by the Sichuan Agricultural University (No. IRT0848).
CONFLICTS OF INTEREST
None.
